We can
be your alternative to high priced original equipment chargers. These
models are drop in replacements with matching mounting and wire ends to
the OEM chargers. We
design IN the same quality as our other models and our
3 YEAR WARRANTY
means your not compromising reliability, in fact your probably improving
it. All of the models shown on this page have reverse polarity
protection and are current limited. They don't use fans, or need
overheat protection. Where
required, a drive lock out or other ancillary circuit is supplied. Some
models are programmable for different battery types. If you have a special design contact us, we don't
need large quantities to justify new models.
Standard 117v/60Hz input. Available in 230v
50 Hz.
Replacement OEM Chargers
|
Equipment PN. |
OEM Charger number |
Quick Charge PN. |
|
Genie Scissor
Lifts
GS-1530
GS-1930
GS-2032
GS-2632
GS-2046
GS-2646
GS-3232
GS-3246
Genie Runabout
GR-12
GR-15
GR-20
Genie AWP
DLP-25S
DLP-30S
DLP-35S |
Genie Chargers
66412 or 96211
105739
8029 / 8030
Signet
HB600-24 |
OBAE24v/25AGN
H.W.D 6 x 9 x 6.5"
27 lbs.
|
|
Skyjack
3015
3215
3219
3220
2326
4620
4626
4632
4832
6826
6832
|
Skyjack Chargers
125834AH
128537
|
OBAE24v/25ASJ
H.W.D 6 x 9 x 6.5"
27 lbs.
|
|
JLG Scissor Lifts
1532E2
1932E2
2032E2
2632E2
2646E2
3246E2
1532E3
1932E3
2033E3
2046E3
2646E3
2658E3
|
JLG Chargers
0400170
0400178
2901844
0400220
0400238
0400218
0400177
0400204 |
OB2425
Formally OBAE24v/25A
H.W.D 6 x 9 x 6.5"
27 lbs.
|
|
SnorkelScissor Lifts |
SnorkelScissor Lift
Chargers |
OB2425
Formally OBAE24v/25A
H.W.D 6 x 9 x 6.5"
27 lbs.
|
|
|
Hyster
W40Z
HY1607815
HY2048079
HY2054228
HY2073416
Yale Pallet Truck
MPBO40-E
524245865
580055473
580087314
582003887
|
OB2415PJ
Programmable to charge gels, AGM, and
wet cell deep cycle batteries
H.W.D 7 x 4.5 x 11"
16 lbs.
|
|
|
GNB
Pallet Pro
SVR24251205/6
SPPMP7501225G
Crown
125322 |
OB2425GNB
Programmable to charge gels, AGM, and
wet cell deep cycle batteries
H.W.D 17.5 x 7 x 5"
26 lbs. |
|
|
Yale Pallet Truck
SB175 518128600
580006679
580006680
580010328
585031100
585052900
585056201
SB50 504872800
641783600
643481600
643881600
Cushman
809256
Big Joe
004967-01
004967-02
Hyster
0826615
0826684
2033588
2035708
3010799
Crown Pallet Truck
092221-001
092221-1
109131-001
109131-1 |
Model OPW24v/15A
H.W.D" 7 x 5.5 x 11.75"
16 lbs.
Model OP24v/15A
H.W.D" 7.25 x 5.375 x 11.375"
16 lbs. |
|
|
Delta Q
QuiQ-912
QuiQ-913 |
DQ2425, DQ3620, DQ4818,DQ7212
H.W.D" 4.5 x 9 x 11"
28 lbs. |
TAYLOR DUNN
|
TAYLOR DUNN |
QUICK CHARGE MODEL |
DC VOLTS |
DC AMPS |
AC POWER |
DIMENSIONS
H.W.D. INCHES |
WEIGHT LBS. |
|
7930305A |
TDET24v/25A |
24 |
25 |
117V 60HZ.
6 AMP |
6.5 X 8 X 13 |
26 |
|
7930305 |
TDET24v/25ASC
|
24 |
25 |
117V 60HZ.
6 AMP |
6.5 X 8 X 13 |
26 |
|
7930315
7930515A |
TDET36v/25A |
36 |
25 |
117V 60HZ.
12 AMP |
6.5 X 8 X 13 |
36 |

Charges lead acid wet cells, Easy to
interpret LED charge indicator, ON when charging, OFF when finished.
Drive lock out circuit to prevent vehicle movement while charger is
plugged in. |
|
